Deep Cycle 12V 40Ah ESS battery For UPS / Backup Power Supply in Africa Market
Specifications:
| Item |
Parameter |
Remark |
| Rating Voltage |
12.8V |
|
| Cell Capacity |
≥300min
|
At standard testing condition after standard charging, rest for
10min, then discharging at 1C to 2.2V, recording the discharging Capacity
|
| Battery Capacity |
≥280min |
At standard testing condition after standard charging, rest for
10min, then discharging at 1C to 8.8V, recording the discharging Capacity
|
| Charge Voltage |
14.6V±0.05V |
|
| Impedance |
200mΩ(Max) |
10mΩ(Max) |
| Battery pack Size |
265*156*200mm |
including the protection plate size |
| Charging Mode |
C.C/C.V. |
Constant Current
/Constant Voltage
|
| Charging Method |
Standard Charging 0.2C5A |
Charging Current 0.2C5A |
| Charging Time |
Standard Charging |
7Hrs |
|
|
End of Discharge
Voltage
|
8.8V |
|
| Overcharge Voltage |
3.75±0.025V/cell |
Max 15V/battery |
| Over Discharge Cut Off Voltage |
2.2±0.08V/cell |
Min 8.8V/battery |
| Over Current |
40A±0.2 A |
|
| Short Circuit |
Recover after removing the short circuit load |
|
| Operating Consumption Current |
50uA (Max) |
|
| Operating Temperature |
Charging |
0~45℃ |
|
| Discharging |
-10~45℃ |
| Storage Temperature |
-10℃-45℃
Recommend(25±5℃)
|
Storage capacity should be 40%~50% full charge capacity |
| Cycle Life |
2000 cycle |
|
Description:
(1) certification :CE,ROHS,UN38.3,MSDS approved cells and built-in smart BMS;
(2) Similar SLA battery housing for drop-in replacement;
(3) good quality High stable discharge rate and output vs SLA battery;
(4) 3-5cycle life times longer vs SLA battery;
(5) weight:1/3 lightweight vs SLA battery;
(6) used in Environmental friendly
Applications:
The battery are mainly used in Solar Energy, Wind Power, UPS, EV, backup power supply. Solar lighting, - Electric power system, security system
Our Service:
1. Customized are welcome
2. Support print the logo on products;
3. OEM and ODM are available
4. Products have proceeded comprehensive testing before shipment;
